The 1270 PCA measures the force to open or bend paperboard and scored paper carton. Force data is vital for accurately configuring machinery that controls cartons on form, fill and seal lines and to analyze carton performance for runnability and quality control.

The ability to predetermine settings in the production of cartons can increase overall efficiency. Maintaining identical package specifications between the producer and the packager has also shown to be of mutual benefit for increasing savings in less reworks, rejects and down-time. The 1270 PCA also measures spring back after folding providing critical information for sealing or gluing operations.

Opening Force — Measures the maximum force required to open a flat folded carton along score lines.

Bending Force — An optional bending fixture measures the maximum force to bend a carton sample up to 90°. Measure bending stiffness, score ratio of scored vs unscored paperboard and carton fold springback force.

Coefficient of Friction (COF) — Model 1270 PCA includes necessary software to measure static and kinetic coefficient of friction.Features

Software Includes:

Opening Force, Bending Force & COF Test Modes

Statistics include average, high, low and standard deviation

Spring Back of Fold Test

Score ratio test mode of scored vs unscored paperboard

Test result and curve data for PC interface

Optional Data Acquisition Software Program

Auto-zero & Semi-automatic calibration

Automatic return with overload protection

RS-232 interface

Bending Fixture

The Bending Fixture uses a pneumatic clamp that is operated with a foot-control pedal. Pneumatic clamping ensures a secure hold and a higher repeatability then manual clamping. The bending plate exerts the force required to bend the sample up to 90 degrees. A set of three reference plates are included that are used to verify accuracy.

COF Fixture

Consists of a sample platform and sled. The platform provides a travel distance of 203 mm (8 inches). The platform quickly mounts to a support plate above the bending fixture which minimizes time to switch between bending and COF testing.
